DPDT & SPDT SLIDI SWITCH

DPDT & SPDT SLIDI SWITCH :- Slide Switches are an electromechanical device used to control current flow in a circuit path. Devices in this family are actuated by sliding a…

Continue Reading DPDT & SPDT SLIDI SWITCH

Rocker Switch

Features :-

  1. Switch Type: SPST
  2. Contact resistance: <50mΩ
  3. Insulation resistance: >100MΩ
  4. Dielectric resistance: >1500VAC / 1 min
  5. Material type: Plastic

Continue Reading Rocker Switch

Arduino of Automotive World: ElecronicsV2

Board Specification: –

  • S32K144 MCU in LFQP100 pin package.
  • onboard RGB LED and 2 switches
  • 1 Variable Potentiometer
  • On-board UART for debugging via Type C USB cable
  • On-Board CAN transceiver IC TJA1051 via green screw Terminals.
  • TX-RX LED indicator pins for onboard UART and CAN communication.
  • Onboard JTAG-SWD 10-pin Connector for JLink SWD Debugging

Continue Reading Arduino of Automotive World: ElecronicsV2

S32K144 Microcontroller Development Board: ElecronicsV2

  • S32K144 MCU in LFQP100 pin package.
  • onboard RGB LED and 2 switches
  • 1 Variable Potentiometer
  • On-board UART for debugging via Type C USB cable
  • On-Board CAN transceiver IC TJA1051 via green screw Terminals.
  • TX-RX LED indicator pins for onboard UART and CAN communication.
  • Onboard JTAG-SWD 10-pin Connector for JLink SWD Debugging

Continue Reading S32K144 Microcontroller Development Board: ElecronicsV2

Arduino Uno For Beginners Kit

PROJECTS CODE Download The Arduino ide Software Try it for free . No registeration needed. Download Now Get Code Arduni Uno Code for Beginner Led Blink This example shows the…

Continue Reading Arduino Uno For Beginners Kit

DS3231 Real Time Clock (RTC) Module

Specifications & Features of DS3231 Real Time Clock (RTC) Module:-

  1. Two Time-of-Day Alarms.
  2. Digital Temp Sensor Output.
  3. Register for Aging Trim.
  4. DS 3231 RTC with 2032 Battery Holder.
  5. Highly Accurate RTC Completely Manages All Timekeeping Functions.
  6. Real-Time Clock Counts Seconds, Minutes, Hours, Date of the Month, Month, Day of the Week, and Year, with Leap-Year Compensation Valid Up to 2100.
  7. Configurable I2C device Address for AT24C32 using SMD jumpers on PCB (A0, A1, A2).
  8. Programmable Square-Wave Output Signal.
  9. Battery-Backup Input for Continuous Timekeeping.
  10. Low Power Operation Extends Battery-Backup Run Time.

Continue Reading DS3231 Real Time Clock (RTC) Module

Soil Moisture Meter, Soil Humidity Sensor, Water Sensor, Soil Hygrometer

Specifications & Features of Soil Moisture Meter, Soil Humidity Sensor, Water Sensor, Soil Hygrometer:-

  1. Dual output mode, analog output more accurate
  2. A fixed bolt hole for easy installation
  3. With power indicator (red) and digital switching output indicator (green)
  4. Having LM393 comparator chip, stable.
  5. Operating Voltage: 3.3V~5V

Continue Reading Soil Moisture Meter, Soil Humidity Sensor, Water Sensor, Soil Hygrometer
